Last year, the Cox Connected Environments Collaboratory began working with ASU stakeholders across departments in an effort to help the university further its sustainability goal to become Climate Positive. This means ASU is working towards a net positive impact, a business approach that allows the university to give back to society, the environment and the economy.
Part of these efforts includes the electrification of ASU’s vehicles and installation of electric charging stations across all university campuses to create a smarter, more sustainable fleet. The Cox Collaboratory is currently in the process of collecting and verifying data over a six-month project that will provide ASU stakeholders with the right information to right size the fleet and properly place charging stations for this all-electric vehicle fleet.
“We have hundreds of ASU vehicles in use across our campuses, serving the needs of various departments,” said Alex Kohnen, Vice President, Facilities Development and Management at ASU. “By tracking their usage, we can make data-informed decisions to really reduce our fleet to match the needs of the university.”
Leveraging Cox’s network to gather data in real time
Data collection for the Fleet Data Pilot began in December 2021 with a fleet of about 500 vehicles — including a mix of SUVs, sedans and carts — that had devices installed to monitor their activity. The Cox Collaboratory used two different technologies for tracking the fleet: Cox’s LoRA (Long Range) networks, as well as cellular for when vehicles traveled outside the reach of the LoRa network.
The vehicles on campus connect using Cox’s LoRA network, which is a long range, low-power wireless network that offers secure data transmission – this cost-effective solution is ideal for capturing data from vehicles that don’t travel long distances, like the university’s DART carts. The LoRA network’s gateways can be found on the rooftops of three of the tallest buildings around ASU’s Tempe Campus.
Cox Collaboratory Growth Manager Angela Saurini explained that the height of the buildings matters for this type of network, which extends coverage in a circular space downwards: “Think of coverage like an open umbrella – the higher the building, the wider our network’s coverage extends,” Saurini shared.
To do so, the LoRA network’s gateways each have two 6-foot antennas that allow the Collaboratory to communicate with the devices on the vehicles. A 240-foot cable connects the gateway antennas on the rooftop to the modem inside of each building to accommodate for Arizona’s high temperatures. This modem is what provides the wireless internet capability.
A few weeks into the pilot, the Cox team noticed a lag in the connection around the southeastern corner of campus. In response, Saurini set up a smaller, more temporary LoRA gateway (with 2-foot antennae instead of 6-foot) at the University Services Building (USB). This ensures the LoRA network could cover the majority of the Tempe campus.
And for the vehicles that go beyond the area in which these three LoRA networks cover, cellular connection is used to monitor the fleet, giving the team an extended range to collect data.
Capturing the right data to inform the future of the fleet
Because each department utilizes its own fleet of carts, cars and SUVs, it's important for the Collaboratory team to gather vehicle activity. The Smart Fleet Data Pilot research team monitors the distances traveled by vehicle type, fuel consumption, greenhouse gas generated, vehicle usage and more. With this information, the team will know the behavior of the vehicles to better inform decision makers on the types of cars needed and where new electric charging stations should be placed around campus.
“Once we verify the data, we can share the current status of how vehicles are being used,” said Hongbin Yu, Associate Professor for ASU’s School of Electrical, Computer and Energy Engineering and the Center Director of the university’s Center for Efficient Vehicles and Sustainable Transportation Systems. “This information is also critical for us to come up with a model or suggestion on how to reduce the fleet and convert [to electric].”
Ideally, Yu says the models will allow the research team to provide quantitative data to key stakeholders of the Smart Fleet initiative to project many different scenarios to develop a strategy. Based on how quickly, aggressively, and costly the university wants to transform the fleet, stakeholders can best determine the next steps for the initiative.
One stop gap in the market, though, is the availability of electric vehicles (EV) that best meet ASU’s needs. For example, there aren’t currently many low-cost SUVs and trucks currently available on the market. But that’s where it’s important to have the data to understand ASU’s usage needs and distance that these larger vehicles typically travel.
Although it’s early in the data gathering process, one finding is already obvious. “Right away, we’ve noted that a lot of vehicles are not being utilized,” said Yu. “We have seen auto and fuel consumption, but not a lot of miles driven.” Kohnen mentioned that a benefit of decreasing vehicle density is that it allows the campus to become a safer place.
The importance of partnership to create impact
When it comes to fueling innovation across ASU, partnership is key. Kohnen is excited about the promise this collaborative work brings to the university. “This pilot is an excellent example of how we can work together to create value for the university, free up resources for our primary mission of educating students and creating world-changing research on campus,” said Kohnen.
The Cox Collaboratory team is happy to provide the data needed to help the university make informed decisions as it transitions to an all electric fleet. “We are very intentional in the data that is shared,” said Saurini. “Using Cox’s wireless technology already installed around campus, we are able to provide ASU the data needed to understand the right sizing the fleet, lower the units of greenhouse gas that are emitted, and determine where the charging stations should be placed.” In turn, the university will be able to leverage this data to be more operationally efficient, support a fleet and migrate to an all-electric fleet.
“It isn’t an individual change that makes an impact,” she added. “But when we come together as an entire university to be more intentional in how we use resources like our vehicles, that is how we can create more sustainable change.”
Many thanks to our featured interviewees:
Alex Kohnen, Angela Saurini and Professor Hongbin Yu
